Specifications :
| External Size (W*D*H) | 700*650*1920mm |
| Internal Size (W*D*H) | 600*500*540mm |
| Work Surface Hight | 750mm |
| Max Opening | 370mm |
| Tested Opening | Safety height 254mm (10″) |
| Inflow | 290m³/h (170cfm) |
| Downflow | 55%: 360m³/h (211cfm) |
| Exhaust | 45%: 290m³/h (170cfm) |
| Front Window | Two-layer laminated toughened glass>6mm, Anti UV |
| ULPA Filter | ≥99.9995% efficiency at 0.12μm |
| Filter Guard Type | Aluminum alloy frame |
| Noise | NSF 49≤67 dB |
| Illumination | ≥1000Lux |
| Display | Capacitive touch screen |
| Waterproof Socket | Two, Total consumption≤500W |
| Ground Resistance | ≤0.1Ω |
| Power Supply | AC230V, 50/60Hz; AC115V, 60Hz |
| Consumption | ≤500W |
| Alarm | Abnormal airflow velocity; Filter replacement; Front window at unsafe height |
| Motor | One EC fan, 115V＆230V acceptable, Speed adjustable, High efficiency and low power consumption |
| Material | Working area: 304 stainless steel |
| UV Lamp | Frame and Decorative Plate: cold-rolled steel with anti-bacteria power coating |
| LED Lamp | 15W |
| Net Weight | 150kg |
| Package Size (W*D*H) | 800*850*1350mm |
| Gross Weight | 170kg |
Catalog : PDF
