Specifications :
| Display Type | LCD large-screen | Current Output | Type: 2 Isolated 4 to 20mA |
| Measurement Range | 0.00~2.00mg/L (ppm) | Range: Selectable zero & span | |
| 0.00~5.00mg/L (ppm) | Accuracy: ±0.02mA | ||
| 0.00~10.00mg/L (ppm) | Maximum load: 750Ω | ||
| -1.00~15.00pH | Cleaning
(Optional) |
Control type: On/off | |
| 0.0~100°C | Control time: Duration & interval | ||
| Resolution | 0.01mg/L (ppm) | Communication
(Optional) |
RS485 |
| 0.01pH | |||
| 0.1°C | Power Supply | AC110V~220V±10% , 50/60Hz | |
| Accuracy | ±1% F.S mg/L (ppm) | Security Protection | 4digit password |
| ±0.2% F.S pH | Weight | 850 grams | |
| ±0.2°C | Dimensions | 144×144×125mm | |
| Temperature Compensation | Automatic / manual | Mount Type | Panel / Wall |
| 0~100°C | Cut-out Size | 135×135mm | |
| Output Relays | Free Chlorine: 2 programmable | Protection Degree | IP65 |
| pH/Temperature: 2 programmable | Ambient Temperature | -10~+55°C | |
| Control type: On/off | Relative Humidity | 5% to 95% noncondensing | |
| Relay set point hysteresis:
User programmable |
Max Operating Altitude | 10,000 feet (3,000 m) |
Catalogue : PDF
See more products GOLDPOINT brand.
