Specifications:
Technical parameterse
- Overall size：369*145*150mm (L*W*H)
- Measurement accuracy： Single shooting： ±2%; Stitching shooting：length and width ± 2%, the rest of the data is ± 5% (the result of blade stitching with a width that is too narrow (< 5mm) will have errors)
- Measurement range： Single shooting: width 0-140mm, length 0-105mm；Stitching shooting：width 0-140mm, length 0-∞mm
- Product weight：0.9KG
- Software system：Android8.1
- Phone size：6.26 inches
- Rear camera： Rear four cameras：48 million (color, F1.8 aperture) + 8 million (super wide-angle) + 2 million (macro) + 2 million pixels (depth)
- Resolution：1920×1080 pixels
- RAM：6GB+128GB
- CPU：HUAWEI Kirin 810 (Kirin 810) eight core
- Blade length measurement range: single acquisition range is 0-110 mm (supports multiple images stitching, the longest is at least 2m)
- Blade length measurement accuracy: single acquisition measurement accuracy is ±1%, splicing accuracy can be controlled within ±2%
- Blade width measurement range: 0-150 mm
- Blade width measurement accuracy: single acquisition measurement accuracy is ±1%, splicing accuracy can be controlled within ±2%
- Aspect ratio measurement range: 0.00-10.00
- Measurement accuracy of aspect ratio: single acquisition measurement accuracy is ±2%, splicing accuracy can be controlled within ±2%
- Perimeter measurement range: 0-1,000 mm
- Perimeter measurement accuracy: single acquisition measurement accuracy is ±2%, splicing accuracy can be controlled within ±3%
- Area measurement range: 0-1,000,000 mm2
- Area measurement accuracy: single acquisition measurement accuracy is ±1%, splicing accuracy can be controlled within ±2%
- Form factor range: 0.00-1.00
- Form factor measurement accuracy: single acquisition measurement accuracy is ±2%, splicing accuracy can be controlled within ±5%
- Shape factor range: 0.00-1.00
- Shape factor measurement accuracy: single acquisition measurement accuracy is ±2%, splicing accuracy can be controlled within ±5%
Catalogue: PDF
