Specifications :
| Project | Parameter |
| Measuring Range | 1~9999 times (the range can be increased as needed) |
| Folding angle | 135°±2° |
| Folding speed | (175±10) times/min |
| Tension adjustment range | 4.9N~14.7N |
| Folding head stitching specifications | 0.25mm, 0.50mm, 0.75mm, 1.00mm |
| Folding head width | 19±1mm |
| Folding corner radius | R0.38mm±0.02mm |
| The tension change caused by the eccentric rotation of the folding chuck is not greater than | 0.343N. |
| Power supply | AC220V±10% 50Hz |
| Working Environment | Temperature 0~40℃, relative humidity no more than 85% |
| Dimensions | 390 mm (length) × 305 mm (width) × 440 mm (height) |
| Gross weight | ≤ 21kg |
Catalog : PDF
