Specifications :
| Display Type | LCD large-screen |
| Measurement | -1.00 ~ 15.00pH |
| Range | -1999mV ~ +1999mV |
| 0.0 ~ 100°C | |
| Resolution | 0.01pH |
| 1mV | |
| 0.1°C | |
| Accuracy | ±0.2% F.S pH |
| ±0.2% F.S mV | |
| ±0.2°C | |
| Temperature | Automatic / manual |
| Compensation | 0 ~ 100°C |
| Output Relays | pH/ORP: 2 programmable |
| Temperature: 2 programmable | |
| Control type: On/off | |
| Relay set point hysteresis: | |
| User programmable | |
| Current Output | Type: 2 Isolated 4 ~ 20mA |
| Range: Selectable zero, & span | |
| Accuracy: ±0.02mA | |
| Maximum load: 750Ω | |
| Cleaning
(Optional) |
Control type: On/Off |
| Control time:Duration & interval | |
| Communication
(Optional) |
RS485 |
| Power Supply | AC110V~220V±10% |
| 50/60Hz | |
| Security Protection | 4digit password |
| Weight | 680 grams |
| Dimensions | 144×144×125mm |
| Mount Type | Panel / Wall |
| Cut-out Size | 135×135mm |
| Enclosure Rating | IP65 |
Catalogue : PDF
