Specifications:
| Technical Data | LS-50HV | LS-75HV | LS-100HV |
| Chamber volume | 50L
фЗ40 х 550mm |
75L
ф 400 x 600mm |
100L
ф440 x 650mm |
| working pressure | 0.22 Mpa | ||
| Working temperature | 134℃ | ||
| Max working pressure | 0.23Mpa | ||
| Heat average | ≤±1℃ | ||
| Timer range | 0~99min | ||
| Temperature adjust range | 0~134℃ | ||
| Power | 3000W/AC220V50Hz | 4500W/AC220V50Hz | 4500W/AC220V50Hz |
| Overall dimension | 690x 470x 1140 | 730x510x 1270 | 750x550x1305 |
| Transport dimension | 760 x 550x 1290 | 820x 600x 1380 | 840x640x1410 |
| G.W/N.W | 120Kg/100Kg | 140Kg/118Kg | 160Kg/128Kg |
