Specifications:
| Spherical power | 27.00mˉ¹~-27.00mˉ¹(0.25mˉ¹/0.50mˉ¹/1.00mˉ¹/3.00mˉ¹) |
| Astigmatic power | 8.00mˉ¹~-8.00mˉ¹(0.25mˉ¹/1.00mˉ¹) |
| Cylinder axis | 0~180°(1°/5°) |
| Prism | 0~20∆(all direction)(0.1∆/0.2∆/0.5∆/1.0∆) |
| Pupillary distance adjustment range | 48~80mm (0.5mm/2.0mm) |
| Cross cylinder | Auto Jackson cross cylinder:±0.25mˉ¹ |
| Testlen(au lens) | Rea-Green filter, Polarized filter(45 135), prism(6∆/10∆)
Rea Maddox(horizontal/vertical), lens of retinoscopy( 1.5mˉ¹/ 2.0mˉ¹) cross cylinders for presbyopia(0.50mˉ¹), Occluding plate(left/right), Pinhole and cross hairs glass (left/right). |
| Cornea alignment scale (on optical axis) | 12mm, 13.75mm, 16mm, 18mm, 20mm |
| Convergence | Near-point distance 40/67 cm (Minimum pupillary distance at 40cm convergence: 53mm) |
| Forehead reset adjustment range | 15mm |
| Main Unit
|
300-330mm(W)×120mm(D)×300mm (H) |
| 4.5KG | |
| Supply Unit
|
230mm(W)×100mm(D)×110mm (H) |
| 2KG | |
| Touch-Screen Controller
|
300mm(W)×225mm(D)×203mm (H) |
| 1.8KG |
Catalogue: PDF
