Automatic Interfacial Tension Tester GD-6541A

Automatic Interfacial Tension Tester GD-6541A

Features :

Large LCD screen;
Sample cup: to hold sample to be measured;
Fine adjustment for zero point;
Fine adjustment for full scale;
Ring rod;
Platinum ring;
Sample support;
Blank buttons;
Background light button;
Instrument foot: to level the instrument;
Printer and computer port;
Fuse box with fuse of 1A;
Power switch;
Power supply socket;

SKU: GLD-GD-6541A-Automatic Interfacial Tension Tester Category: Lab Equipment Tags: Automatic Interfacial, Automatic Interfacial GD-6541Z, Automatic Interfacial Tension Tester, Automatic Interfacial Tension Tester GD-6541A, Automatic Tension Tester, Automatic Tension Tester GD-6541A, GD-6541A, Interfacial Tension Tester, Interfacial Tension Tester GD-6541A, Tension Tester, Tension Tester GD-6541A

Specifications :

Model: GD-6541A
Display method: It has a large LCD screen with background light and prompt menu. The menu contains all test procedures and calculation methods stipulated in the GB/T6541;
Buttons: Blank buttons;
Measurement range:
For insulating oil: 2～100 mN/m;
For other petroleum products: 2～200 mN/m;
Sensitivity: 0.1 mN/m;
Accuracy: 0.1 mN/m;
Resolution: 0.1 mN/m;
Repeatability: 0.3%;
Ambient temperature: 10℃～30℃;
Relative humidity: 20%～75%;
Power supply: AC 220V±5%, 50 Hz;
Rated power: not more than 100 W;
Size: 185 mm×260 mm×360 mm;
Weight: 15 kg;

Catalog : PDF
