Specification:
| Dynamometer | digital AC inverter motor, oscillating bearing | |
| Power | 3.8 kW | |
| Speed | 0.2 – 150 min -1 | |
| Rpm constancy | quartz accurate due to digital feedback | |
| Torque measurement | Electronic | |
| Torque measuring range | 0 – 200 Nm | |
| Accuracy | better than ± 0.5% of the selected measuring range | |
| Direction of rotation | right | |
| Mains connection | 3 x 400V, 50/60 Hz, +N +PE optional 3 x 200 V, 50/60 Hz, +N +PE, 32 A |
|
| Dimensions (B * H * T) Desktop unit without stand |
650 * 480 * 1150 mm | |
| Weight without base | approx. 150 kg |
Catalogue: PDF
