Specifications:
Applications
TP3-18K desktop high-speed centrifuges are widely used in clinical medicine, biochemistry, genetic engineering, immunology and etc. It is essential equipment for hospitals, research institutes and universities.
Technical Parameter
|
Model
|
TP3-18K
|
|
Max RPM
|
18500rpm
|
|
Max RCF
|
23900×g
|
|
Max Capacity
|
4×100ml
|
|
Timer
|
1min～99min
|
|
Revolutions/min
|
±10r/min
|
|
Voltage
|
AC 220±22V 50Hz 10A
|
|
Power
|
500W
|
|
Noise Level
|
≤ 60dB（A）
|
|
Chamber Diameter
|
Φ320mm
|
|
Dimensions (L x W x H)
|
440×360×330 (mm)
|
|
Packaging Dimensions
|
545×430×395(mm)
|
|
Net Weight
|
28kg
|
|
Gross Weight
|
35kg
|
|
Rotor Type
|
No.
|
Capacity
|
RPM（r/min)
|
RCF(×g)
|
|
Angel Rotor
|
1
|
12×1.5/2.2ml
|
18500rpm
|
23900×g
|
|
2
|
18×0.5ml
|
16000rpm
|
16000×g
|
|
|
3
|
10×5ml
|
15000rpm
|
15940×g
|
|
|
4
|
24×1.5/2.2ml
|
14000rpm
|
18757×g
|
|
|
5
|
36×1.5/2.2ml
|
14000rpm
|
20025×g
|
|
|
6
|
12×10ml
|
13000rpm
|
17370×g
|
|
|
7
|
6×50ml/ Round type
|
12000rpm
|
15285×g
|
|
|
8
|
6×50ml/ Sharp type
|
11000rpm
|
12840×g
|
|
|
9
|
12×15ml/ Sharp type
|
10000rpm
|
9690×g
|
|
|
10
|
4×100ml
|
10000rpm
|
9690×g
|
Catalogue: PDF
