Specifications :
| Detection gas | 6 kinds (Max 8 kinds) of gas concentration and temperature and humidity |
| Detection principle | electrochemical, catalytic combustion, infrared, thermal conductivity, PID light ions, according to gas, range, site environment and user requirements |
| Detection method | built-in pump, flow 500 ml / min |
| Accuracy | ≤± 2% F.S (2% of full range), temperature:0.5℃, humidity: 3% RH |
| Installation | pipe, wall-mounted. Pipeline working pressure of atmospheric pressure ± 30%, beyond the scope of the need to step-down treatment |
| Response time | T90 ≤ 20 seconds |
| Recovery time | ≤ 30 seconds |
| Output signal | RS485 (RTU), three (four) line 4~20mA |
| Optional | 0~20mA,1~5V, 0~5V, 0~10V,wireless transmission |
| Alarm mode | sound and light alarm (optional), the default 1 way, optional 3 relay output, alarm value can be set |
| Working temperature | -40~70℃ |
| Working environment humidity | 10 ~ 95% RH non-gel; can reach 0-99%RH for Special requirement. |
| Power | 24VDC(11~30VDC) |
| Explosion-proof grade | Ex d IIC T6 |
| Protection grade | IP66 |
| Size | 210×170×85mm |
| Weight | 1.8kg |
| Application | chemical, petroleum, pharmaceutical, environmental flue gas analysis, pipeline, boiler gas analysis, air treatment and other needs to detect the concentration of gas occasions |
