Specifications:
| TR-500 | ||
| Mechanical Parameters | Up/Down angle of swing arm | ±30° |
| Table size | 840mmx405mm, 670mmx405mm | |
| Table rotational angle | 90° | |
| Chair height adjustment range | 410~550mm | |
| Loading for chair | 150kgs | |
| Electrical Parameters | Input voltage | 110V/220V AC 50Hz～60Hz |
| Engine power | 55W 220V AC | |
| Light | 40W 110V/220V AV | |
| Fuse | 5A 250V AC | |
| No load power | 1W | |
| Pressure test | 2KV | |
| Main wire | 10A 250V | |
| Working mode | S1 | |
| Working temperature | -10℃~ 40℃ | |
| Relative humidity | less than 90% | |
| Installation Dimension | Figure size | 1200mm*1000mm*2130mm |
| Weight | 150kgs | |
Catalogue: PDF
