Specifications:
| Rated Power | 500VA-10KVA |
| Input Voltage | Single phase(110V, 120V, 200V, 220V, 230V or 240V)±1%~5%(Can be customized) |
| Frequency | 50Hz/60Hz |
| Output Voltage | Single phase voltage(110V, 120V, 200V, 220V, 230V or 240V) |
| Output Voltage Accuracy | ±1%~5%(Can be customized) |
| Power Factor | PF≥1 |
| Efficiency | ≥98% |
| Response Time | ≤0.5S |
| Waveform Distortion Factor | ≤1℅ |
| Protection Function | Protect against overvoltage, undervoltage, overload, short circuit; and bypass protection |
| Display | Led display(Input voltage and output voltage) |
| Cooling Method | Air Cooling |
| Insulation Resistance | ≥2MΩ |
| Dielectric Strength | 2000VAC/Min without breakdown |
| Noise | ＜65dB/m |
| Working Temperature | 0℃-45℃ |
| Working Humidity | 20â„…-90â„… |
