Specifications:
| Frequency | 50MHz/35MHz(optional) |
| Scanning Mode | Linear Scanning |
| Scanning Range | 16mm*9mm; 10mm*6.5mm |
| Image Resolution(full screen) | 50um |
| Output | PDF report output |
| Scanning Lines | 1024 lines, 15 um between each, high density & high resolution |
| Geometry Distortion | Linear scan, no distortion, no compensation, undistorted image |
| Probe | Multi-Dimension, precise locating articulated arm |
| Probe | Multi-Dimension, precise locating articulated arm |
| Measurement | Distance, angle , perimeter , area |
| Display colors | 12 false colors |
| Display Mode | UBM, UBM A |
| Magnify | Special independent ultrasound magnifies system, better image in Anterior Segment. |
| Eye Fixation | Unique Eye position and LED system |
| Working Platform | Windows XP, VISTA, WINDOWS7 |
| Image Process | Length, angle measurements |
Catalogue: PDF
