Specifications:
| Measurement mode | Cornea/ refractometry measurement mode | keratometry/refractometry |
| Mode of keratometry | refractometry | |
| Refractometry measurement mode | keratometry | |
| Mode of CLBC | Substrate curvature of contact lens | |
| Refractometry | Vertex Distance | 0, 10, 12, 13.5, 15mm |
| Spherical degree | -25.00~ 22.00D(VD=12mm, 0.12 or 0.25D ) | |
| Cylinder degree | 0.00~ + /-10.00D(0.12 or 0.25D) | |
| Axial | 1~180 °（step 1°） | |
| Cylinder Symbol | -, , /- | |
| pupil distance | 10~85 ㎜ | |
| Minimum pupil diameter | ￠ 2.0 ㎜ | |
| Measuring time | 0.07sec | |
| Keratometry | Radius of curvature | 5.0 ~10. 2 ㎜ |
| Corneal refractometry | 33.00 ~ 67.50D | |
| Corneal astigmatism | 0.00 ~ -15.00D （ 0.05/0.12/0.25D ） | |
| Corneal diameter | 2.0 ~ 14.0 ㎜ | |
| Others | printer | Thermal printer |
| Saving Settings | 3, 5, 10 Minutes | |
| Monitors | 5.6 inch of TFT monitors | |
| Power | AC 100 ~ 240V,50/60HZ/90W | |
| Size / Weight | 248(W ) × 476(D) × 475(H) ㎜ /21㎏ | |
| Jaw panel | Max 55 ㎜ | |
| Data Output | Rs-232 interface , Video output |
Catalogue: PDF
See more products Vision Star Optical Co. ltd. brand.
