Specifications:
Technical Data | DST-1 |
Length | 2100±10mm |
Max height | 1000±10mm |
Width | 500±10mm |
Min height | 750±10mm |
Front tilt | ≥22° |
Back tilt | ≥22° |
Lateral tilt | ≥15° |
Backward and forward movement | 400±10mm |
Head plate adjusted upward | ≥45° |
Head plate adjusted downward | ≥90° |
The backboard adjusted upward | ≥75° |
The leg board adjusted downward | ≥90 |
Outreach legs plate | ≥90° |
Life of waist section | ≥120mm |
Power supply | AC 220±10% 50Hz |
Packing volume | Length1405*width725*height885mm |
Catalogue: PDF
See more products Vision Star Optical Co. ltd. brand.
