Specifications:
| Sphere Power | Range | 16.75 to -19.00 diopters |
| Step | 0.25 diopters | |
| Range | 0.00 to -6.00 diopters(0.00 to -8.00 diopters with additional lens of -2.00 diopters) | |
| Cylinder Power | Step | 0.25 diopters |
| Cylinder Axis | 0 to 180°, 5°step | |
| Cross Cylinder | ±0.25 diopters | |
| Rotary Prisms | 0 to 20, 1 step | |
| (O)-Open aperture (two positions) | ||
| (R)-Retinoscopic lens, 1.50D | ||
| (P)-Polarizing lens 45-left eye, 135-right eye | ||
| (WMV) or (RMV)-Maddox rod, vertical white-left eye red-right | ||
| (WMV) or (RMV)-Maddox rod, horizontal white-left eye red-right | ||
| Auxiliary Lens Dial | (RL)-Red lens | |
| ( .12)- 0.12D sphere | ||
| (PH)-Pin hole | ||
| (10 L) or (6 U)-10 base-in-left eye | ||
| 6 base-up-right eye | ||
| (Dissociating prisms)(±.50)-±0.50 fixed cross cylinder | ||
| (OC)-Occluder | ||
| PD Adjustment | 48~75MM, 1MM steps | |
| Standard Accessory Lenses | wo-.12D and -2.00 cylinder lenses, two plano lenses for sealing front opening | |
| Standard Accessories | 1 near point card with holder and reading rod, dust cover, face shield, accessory case for lenses | |
| Dimensions | 400*350*160MM | |
| Net Weight | 4.38 KGS | |
Catalogue: PDF
