Specifications:
| MICROSCOPE | |
| Microscope Type | Parallel Stereomicroscope |
| Eye Piece | 12.5X |
| Magnification | 6X, 10X, 16X, 25X, 40X |
| Field of View | 35mm, 23mm, 14mm, 9mm, 5.5mm |
| Adjustable Pupil Distance | 55-75mm |
| Adjustable Diopter | ±5D |
| Fixed Lamp | Red LED |
| SLIT | |
| Slit Width | O~14mm adjustable |
| Slit Height | 1~ 14mm adjustable |
| Slit Angle | O~180° |
| Aperture Diameter | Ø0.3mm, Ø2mm, Ø5.5mm, Ø9mm, Ø14mm |
| Filter | Heat-absorption, Grey, Red free, Cobalt blue |
| Illumination Bulb | 12V/30W, Halogen bulb |
| POWER | |
| Voltage/Frequency | AC 110/220V~±10%, 60Hz/50Hz |
| Power | 80VA |
| PACKING | |
| Dimension | 72* 50 * 48cm |
| GW | 23KG |
| NW | 17KG |
| OPTIONAL | Applanation Tonometer, Elevating Table, Beam Splitte, Camera Adaptor, CCD Adaptor, Teaching Tube |
Catalogue: PDF
See more products Vision Star Optical Co. ltd. brand.
